Working with Bluetooth Manager
P/N 7010-0752
5-13
authentication, then a passkey must be entered. Once
Authentication is selected, the Passkey can be edited.
• Encryption: secures all data sent over Bluetooth.
• Service Mode: BTManager allows the GMS-2 to connect with
other Bluetooth-enabled devices using serial port or dial-up
services. The connecting device needs to support the service
selected:
• SPP (Serial Port Profile): provides serial port connection with
peripheral Bluetooth-enabled devices, including GPS
receivers which normally do not require authentication.
• DUN (Dial-up Networking Profile): provides a standard to
access dial-up services over Bluetooth. The most common
scenario is using a mobile phone as a modem.
Pairing Bluetooth Devices
The Pairing Mode allows a remote Bluetooth-enabled device to
initiate a request to pair with the GMS-2. If the Pairing Mode option
is activated, then the GMS-2 switches to Pairing Mode for two
minutes. During this two-minute period, any remote device can
attempt to pair with it.
The GMS-2 accepts the first pairing request if the security settings on
the remote device match the GMS-2 security settings. You do not
need to activate the Pairing Mode option if the GMS-2 initiates the
pairing request.
Typically, Topcon Bluetooth-enabled GPS receivers
do not require a PIN upon connection. If it is
necessary, however, the PIN (up to 16 characters)
can be set for a Topcon GPS receiver by BTCONF,
the Topcon Bluetooth module configuration
program.
Topcon Total Stations require a PIN on connection.
Typically, the PIN value is set to “1111”. This value
can be changed.
GMS-2_OM_Book.book Page 13 Friday, December 28, 2007 1:47 PM
