Powering the GMS-2
P/N 7010-0752
2-5
Figure 2-4. Installing the Primary Battery
Replacing the Backup Battery
The backup battery ensures GPS and clock settings are saved when
the primary battery and internal rechargeable battery are depleted.
Under normal conditions, the backup battery lasts two to three years.
The backup battery is a CR2032 coin battery that can be purchased at
many general retailers. You will need Phillips-head and flat-head
screwdrivers to replace the backup battery. Follow these steps to
replace the backup battery (Figure 2-5).
1. If needed, back up data on the internal CF card. See “Backing up
Windows CE RAM Data” on page 3-9 for details.
2. Open the battery cover and remove the primary battery.
3. Using a Phillips-head screwdriver, remove the coin battery cover.
4. Using a flat-head screwdriver, insert the tip of the screwdriver in
the slot to the left of the coin battery. Gently push the coin battery
The Windows CE RAM has a separate backup,
rechargeable battery. This battery will power the
RAM for five minutes after removing the primary
battery.
GMS-2_OM_Book.book Page 5 Friday, December 28, 2007 1:47 PM
