Powering the GMS-2
P/N 7010-0752
2-3
Figure 2-2. Charging the Battery in the GMS-2
To charge the battery using the optional charger (Figure 2-3):
1. Remove the battery from the GMS-2 (see “Installing the Battery”
on page 2-4 for details), and slide it onto the charger.
2. Plug the charger into a grounded outlet.
Figure 2-3. Charging the Battery in the Charger
Charge LED
To Grounded Outlet
GMS-2_OM_Book.book Page 3 Friday, December 28, 2007 1:47 PM
