GMS-2 Specifications
P/N 7010-0752
A-3
Power
Internal battery 2200 mAh (BT-62Q) / 2400 mAh (BT-66Q)
Operating time No less than 7 hours
External power 1 port
Input voltage 8 to 15 V DC (for work)
10 to 15 V DC (for charge battery)
Consumption 2.1 W (with WinCE and GPS receiver turned on)
Battery charger Connect the AC adaptor to charge the power port.
Available run charge when connected to a portable
external power source.
Charging time ~6 hours for full charge
On-board Backup battery for timekeeping; replaceable button-type
battery; 8–10 years normal operation
Connectors and Slot
Serial port 1 port for communication with the GMS+ board (port A);
small connector
USB port 1 port for Windows CE; type B mini ver 1.1; connect to
PC using ActiveSync
External power port 1 port; DC Jack type A; for connecting the AC adaptor or
external battery
External antenna
connector
Lemo connector (EPS.01.250.DLN); 5 VDC output to
external antenna
SD card slot 1 slot for memory storage and I/O
Communication
Serial port Port A of GPS+ board
Baud rate = 460800, 230400, 115200, 2400, 1200, 600,
300
Flow control = RTC/CTS
Length= 7, 8 (default)
Stop bit= 1 (default, 2
Parity= None (default), Odd, Even
Table A-1. GMS-2 General Specifications (Continued)
