MEASUREMENT IN SEMI-AUTO MODE
1 Use the base stopper to release the main body. Hold the control lever and move the main
body to the operator side.
2 Operate the control lever laterally and vertically to obtain the target eye in the center of control
panel screen.
3 While moving the main body toward the patient, focus the target eye. A vague, reflected align-
ment dot appears on the cornea.
4 Fine-adjust the main body position in all directions so that the alignment dot point comes
within the alignment mark.
