Topcon MC-X1 - Body and Boom; Stick; Hitch

Machine Measurements and Configuration
Taking Machine Measurements
35
Excavator Indicate System P/N: 1022461-01
Body and Boom
Stick
Hitch
Boom Length
Secondary Boom Length
Boom Sensor ID
Body Sensor ID
ΘKƌŝĞŶƚĂƟŽŶ
Secondary
Boom Sensor ID
^ƟĐŬ>ĞŶŐƚŚ
^ƟĐŬ^ĞŶƐŽƌ/
Hitch Sensor ID
DŽƵŶƟŶŐ>ŽĐĂƟŽŶ
The Hitch Sensor may
be mounted on the
Dogbone or the
Hitch/Coupling.
Hanging Attachment
may be selected if
there is no sensor.
