GR-i3
70
Specifications
Excavator Indicate System P/N: 1022461-01
GR-i3
Tabl e 2 lists the GR-i3 specifications.
Table 3. GR-i3 Specifications
General
Supply Voltage 9-32VDC
Supply Current 0.2A typical operating current @ 24VDC
0.3A max. operating current @ 24VDC
Electromagnetic
Compatibility
Applicable Standards
Emissions:
Applicable regulation: EN55022:1994 NA
Immunity:
Applicable regulation: EN55024:1998 A1:2001 and A2:2003
ESD: ±8KV
RF: 27 to 500 MHz 3V/m
Fast transient: ±0.5KV capacitively coupled
Ports CANopen
Wireless BT 2.0/BLE 4.0
Environmental
Operating
Temperature
Wired Operation via CAN: -40°C (-40°F) to +80°C (176°F)
Wireless Operation: -30°C (-22°F) to +60°C (140°F)
Moisture Test NA
Ingress
Protection
IP67
Shock Test 25G 11 ms ½ sine wave each axis
Salt Fog Test ASTM B117-03
Vibration Test 10-2000Hz Random, 7.7 GRMS, 8 hours each axis
Physical
Housing Magnesium alloy and PBT+PC Alloy
Housing
Dimensions
135mm (5.31 in.) x 85mm (3.35 in.) x 36mm (1.42 in.)
Connectors Custom 9-pin Pogo connector
Weight 0.68 Kg. (1.5 lbs)
Signal Tracking
Channels 226 Universal Tracking Channels
Signals Tracked GPS: L1, L2, L2C; GLONASS: L1, L2, L2C; BeiDou: B1, B2; Galileo: E1;
SBAS; QZSS: L1, L2C
