WiFi Antenna
71
Specifications
Excavator Indicate System P/N: 1022461-01
Connector Pinouts
WiFi Antenna
BLACK OMNI ANTENNA, 2.4-2.5 GHZ WI-F1
Topcon P/N: 1020001-01
Manufacturer: LAIRD TECHNOLOGIES
Manufacturer P/N: TRAB24003
Accuracy Standalone H: 1.2 m; V: 1.8 m
DGPS H: 0.3 m; V: 0.5 m
SBAS H: 0.8 m; V: 1.2 m
RTK H: 5 mm + 0.5 ppm x baseline; V: 10 mm + 0.8 ppm x baseline
RTK Initialization Time < 10 seconds
RTK Initialization Reliability > 99%
Conn A - 9-pin Pogo
1 Power
2 CAN H
3 CAN L
4 —
5 —
6 —
7 —
8 Wire DN
9 Ground
Table 3. GR-i3 Specifications
Table 4. WiFi Antenna Specifications
General
Specific
Frequency
2400-2500 MHz
Gain dBi 3 dBi
Mobile Antenna
Mounting Type
NMO
Antenna Material Plastic
Maximum Power 100 W
Item Height 2.7 IN (69 MM)
