Calibrating the Sensors
P/N 7010-0697
3-13
9. Once the boom Pitch value is set to zero, set the boom Roll value
to match the body Roll value.
Figure 3-11. Set Boom Roll Value to Match Body Roll Value
If the body Pitch and Poll has not changed from
when the body sensor was calibrated, enter the
recorded body Roll value for the boom Roll value.
If the body pitch and roll has changed, navigate to
the body sensor and record the new body Roll
value, and enter that new value for the boom Roll
value.
