Topcon X63 - X63 3 D Excavator Indicate System

Introduction
X63/X62 Installation and Calibration Manual
1-2
X63
3D Excavator Indicate System
Topcon’s X63 excavator indicate system contains the TS-1 tilt
sensors, GX-60 Display, MC-R3 Controller, and two GPS antennas
for 3-dimensional control of the machine.
Figure 1-1. TS-1 Tilt Sensors on Excavator
Bucket
Sensor
LS-B10W
LS-B10W
Laser Receiver
Laser Receiver
Body
Sensor
Boom
Boom
Sensor
Sensor
Boom
Sensor
Stick
Stick
Sensor
Sensor
Stick
Sensor
