2: ABOUT YOUR MACHINE
©Tormach® 2021
Specifications subject to change without notice.
Page 18 UM10753: 8L Operator's Manual (Version 0321B)
For the most recent version, see tormach.com/support
2.1 SPECIFICATIONS
Travels
X-Axis 4.5" (114 mm)
Z-Axis 10" (330 mm) with tailstock
Spindle
Spindle Speed
l
Low 180 rpm to 2500 rpm
l
High 350 rpm to 5000 rpm
Through Spindle Bore 1" (26 mm)
Maximum Workpiece Length 10" (254 mm) with tailstock
Maximum Feed Rate
X- and Z-Axis 150 IPM (3.8 m/min)
Tailstock
Taper MT2
Diameter 0.9" (22 mm)
Travel 2.2" (55 mm)
Machine Specifications
Table Length 7.5"(191 mm)
Table Width 4"(102 mm)
Maximum Swing Over Bed 8.3" (210 mm)
Maximum Swing Over Carriage 4.1" (105 mm)
Machine Footprint 50"× 26" (1.2 m × 0.7 m)
Overall System Height 52"(1.3 m)
Typical System Weight 815 lb (370 kg)
Power
Primary Power Required Single-Phase 115 Vac, 50/60 Hz
Recommended Circuit Amperage Dedicated Dedicated 15 A breaker
