7: DIAGRAMS AND PARTS LISTS
©Tormach® 2021
Specifications subject to change without notice.
Page 84 UM10753: 8L Operator's Manual (Version 0321B)
For the most recent version, see tormach.com/support
7.19 STAND PARTS LIST
ID Description Quantity
1 Machine Stand Frame (PN 50553) 1
2 Machine Stand Drawer (PN 50554) 2
3 Machine Stand Chip Drawer (PN 50555) 1
4 Coolant Tank Plug Bung (PN 50566) 1
5 Coolant Tank Caster (PN 50567) 4
6 Coolant Tank Plug (PN 50565) 1
7 Coolant Tank (PN 50563) 1
8 Left Stand Door (PN 50557) 1
9 Right Stand Door (PN 50558) 1
10 Door Latch (PN 50561) 2
11 Coolant Pump Flange (PN 50564) 1
12 Coolant Funnel in Stand (PN 50559) 1
13 Stand Shelf (PN 50556) 2
14 Door Hinge (PN 505601) 4
15 Stand Hinge (PN 505602) 4
16 Hinge Pin (PN 505603) 4
17 Drawer Slide Out (PN 505621) 4
18 Drawer Slide Inner (PN 505622) 4
19 Drawer Slide Bearing (PN 505623) 4
