Tormach 8L - Z-Axis Parts List

7: DIAGRAMS AND PARTS LISTS
©Tormach® 2021
Specifications subject to change without notice.
Page 91 UM10753: 8L Operator's Manual (Version 0321B)
For the most recent version, see tormach.com/support
7.25 Z-AXIS PARTS LIST
ID Description Quantity
1 Ball Screw Shield (PN 37851) 1
2 Z-Axis Ball Screw Spacer (PN 37776) 1
3 Z-Axis Spacer (PN 37850) 1
4 Ball Screw Plate (PN 37775) 1
5 Z-Axis Ball Screw Seal (PN 37772) 1
6 Z-Axis Ball Screw, 555 mm (PN 37771) 1
7 Z-Axis Spacer (PN 37779) 1
8 Ball Screw Coupler (PN 37773) 1
9 Z-Axis Ball Screw Support (PN 37765) 1
10 Ball Screw Cover (PN 37766) 1
11 Z-Axis Motor Mount (PN 37764) 1
12 Stepper Motor (PN 37774) 1
13 Z-Axis Carriage Mount (PN 37769) 1
14 Z-Axis Ball Screw Block (PN 37768) 1
15 Z-Axis Ball Screw Nut (PN 37770) 1
16 Z-Axis Way (PN 37763) 1
17 Rolling Bearing S7200 (PN 51024) 2
18 M4 × 12 Screw (PN 51025) 7
19 Rolling Bearings Ball Screw (PN51026) 1
20 M10 × 1 Lock Nut (PN51027) 1
21 M6 × 20 Screw (PN51028) 4
22 M4 × 16 Screw (PN51029) 4
23 M6 × 35 Screw (PN51030) 2
24 M4 × 8 Phillips head screw (PN51031) 3
25 6 × 40 Taper Pin (PN51032) 2
26 6 × 18 Taper Pin (PN 51033) 2
27 M6 × 16 Screw (PN51034) 2
28 6 × 20 Taper Pin (PN51035) 2
