Tormach 8L - X-Axis Parts List

7: DIAGRAMS AND PARTS LISTS
©Tormach® 2021
Specifications subject to change without notice.
Page 88 UM10753: 8L Operator's Manual (Version 0321B)
For the most recent version, see tormach.com/support
7.23 X-AXIS PARTS LIST
ID Description Quantity
1 X-Axis Base (PN 37780) 1
2 X-Axis Slide (PN 37781) 1
3 Stepper Motor (PN 37774) 1
4 X-Axis Motor Mount (PN 37782) 1
5 X-Axis Motor Adjustment Plate (PN 37784) 1
6 X-Axis Ball Screw Nut (PN 37793) 1
7 X-Axis Ball Screw, 160 mm Long (PN 37792) 1
8 X-Axis Gib (PN 37787) 1
9 Spacer, 2 THK, 10 ID × 14.5 OD (PN 37796) 1
10 X-Axis Ball Screw Bearing Spacer (PN 37789) 1
11 X-Axis Ball Screw Retainer (PN 37788) 1
12 Spacer, 7.5 THK, 10 ID × 14.5 OD (PN 37797) 1
13 X-Axis Ball Screw Pulley (PN 37790) 1
14 Spacer, 3.5 THK, 10 ID × 14 OD (PN 37795) 1
15 X-Axis Ball Screw Support (PN 37794) 1
16 X-Axis Retainer (PN 37785) 2
17 Z-Axis Gib (PN 37786) 2
18 Gib Adjustment Screw (PN 37799) 6
19 X-Axis Motor Pulley (PN 37849) 1
20 Rolling Bearing S7200 (PN51026) 2
21 M10 × 1 Lock Nut (PN 51027) 1
22 Rolling Bearings 619-8 GB 276-94 (PN51037) 1
23 M8 × 35 Socket Head Cap Screw (PN 51038) 2
24 M6 × 25 Screw (PN51039) 2
25 M4 × 8 Set Screw (PN51040) 4
26 M4 × 6 Set Screw (PN51041) 4
27 M4 × 16 Socket Head Cap Screw (PN51042) 4
28 M4 × 12 Screw (PN51025) 3
29 Z-Axis Carriage Mount (PN 37769) 1
