Tormach 8L - Tailstock Parts List

7: DIAGRAMS AND PARTS LISTS
©Tormach® 2021
Specifications subject to change without notice.
Page 86 UM10753: 8L Operator's Manual (Version 0321B)
For the most recent version, see tormach.com/support
7.21 TAILSTOCK PARTS LIST
ID Description Quantity
1 Tailstock Frame (PN 37805) 1
2 Tailstock Base (PN 37806) 1
3 Tailstock Location Cam (PN 37821) 1
4 Fastner (PN 37823) 1
5 Tailstock Lock (PN 37822) 1
6 Tailstock Slide Lock (PN 37816) 1
7 Tailstock Location Lock Block (PN 37819) 1
8 MT2 Adapter (PN 37807) 1
9 Slide Guide (PN 37818) 1
10 Tailstock Slide Screw (PN 37811) 1
11 Tailstock Slide Screw Nut (PN 37808) 1
12 HandWheel (PN 37809) 1
13 Graduation Wheel (PN 37810) 1
14 Slide Lock Mount (PN 37817) 1
15 Tailstock Location Lock Handle (PN 37820) 1
16 Tailstock Handle (PN 37815) 1
17 Spring Plunger (PN 37814) 2
18 Shoulder Screw (PN 37813) 1
19 Tailstock Wheel Handle (PN 37812) 1
