7.17 HEADSTOCK PARTS LIST
ID Description Quantity
1 Dunham 5C Collet Closer (PN 37783) 1
2 Spindle Belt, 8L (PN 37832) 1
3 Spindle Motor Pulley (PN 37830) 1
4 Spindle (PN 37837) 1
5 Spacer (PN 37838) 1
6 Spindle Front Retainer (PN 37835) 1
7 Spacer (PN 37843) 1
8 Spindle Retainer (PN 37844) 1
9 Spindle Rear Retainer (PN 37836) 1
10 Spindle Lock Ring (PN 37845) 1
11 Spacer (PN 37842) 1
12 Draw Tube Knob (PN 37841) 1
13 Collet Draw Tube (PN 37839) 1
14 Spindle Encoder (PN 37826) 1
15 Encoder Spindle Shaft Pulley (PN 37840) 1
16 Spindle Pulley (PN 37831) 1
17 Spindle Encoder Mounting Plate (PN 37829) 1
18 Headstock Frame (PN 37824) 1
19 Spindle Encoder Belt (PN 37833) 1
20 Encoder Pulley (PN 37834) 1
21 Collet Draw Tube (PN 37846) 1
22 Rolling Bearings 6009 (PN51043) 2
23 Rolling Bearings 61909 (PN 51044) 2
24 M6 × 25 Screw (PN51039) 6
25 M5 × 25 Screw (PN51045) 6
26 M5 × 5 Screw (PN51046) 2
27 M6 × 8 Screw (PN 51047) 3
28 M6 × 6 Screw (PN51048) 3
29 6 × 36 Key (PN51049) 1
