Toro Groundsmaster 5900 Series - Cutting Deck Motor Service

CuttingDeckMotorService
14
1
3
1
4
5
6
8
9
12
7
10
2
13
12
13
6
7
15
16
45 N·m
(33 ft-lb)
11
g288023
Figure106
1.Shaftseal(2)
7.Frontthrustplate
13.Seal(2)
2.Retainingring8.Drivegear
14.Rearcover
3.Flangewasher9.Idlergear
15.Capscrew(4)
4.Frontange
10.Rearthrustplate
16.Washer(4)
5.Pressureseal(5)
11.Body
6.Backupgasket(6)12.Dowelpin(4)
CuttingDeckMotorDisassembly(Figure106)
1.Plugmotorportsandcleantheoutsideofthemotorthoroughly.After
cleaning,removeplugsanddrainanyuidoutofthemotor.
MARKER
LINE
g288024
Figure107
2.Useamarkertomakeadiagonallineacrossthefrontange,bodyandrear
coverforassemblypurposes(Figure107).
HydraulicSystem:ServiceandRepairs
Page5–120
Groundsmaster
®
5900&5910
16227SLRevB
