Toro Groundsmaster 5900 Series User Manual

Fuses
Circuitprotectionforthe24VDCsystemincludesa100Ampmegafuse(see
MegaFuses(page6–56))anda5Ampfuselocatedontherearpowercenter.
Theentire12VDCsystemisprotectedbya60Ampmegafuse(seeMegaFuses
(page6–56)).Theindividual12Volttractionunitcontrolcircuitsareprotectedby
avarietyofsmalleramperagefuseslocatedatthefrontorrearpowercenters.
Thefrontpowercenterislocatedbehindtheoperatorseatandtherearpower
centerisintherightrearcornerofenginecompartment.
Groundsmaster5910machines(withcab)includeadditional12VCDcircuit
protectionviaa60Ampmegafuse(seeMegaFuses(page6–56)),a10Amp
fusefortheradioattachedtotherightsideofthecoolersupportframeandeight
(8)fusesinafuseblocklocatedinthecabheadliner.
FuseIdentication,LocationandFunction
1
2
4
5
6
3
FRONT
g288441
Figure197
1.60Ampmegafuseholder(tractionunit)4.25Ampfuse(YanmarECU)
2.Fuse/Diodeholderbase5.5Ampfuse(24Voltalternator)
3.Fuse/Diodeholdercover6.Diode(24Voltalternator)
Raisehoodtoaccessrearpowercenterinrightrearcornerofengine
compartment(Figure197).
•A25AmpfusesuppliespowertoYanmarECU.
•A5Ampfusesuppliespowerto24Voltalternatorsenseterminal.
Groundsmaster
®
5900&5910
Page6–57
ElectricalSystem:ComponentTesting
16227SLRevB

Toro Groundsmaster 5900 Series Specifications

General

Deck Lift	Hydraulic
Cutting Width	16 ft (4.9 m)
Drive System	4WD
Cutting Height	1 - 6 inches (2.5 - 15.2 cm)
Ground Speed	0-17 mph (0-27.4 km/h)
Transmission	Hydrostatic
Turning Radius	Zero-turn
Standard Tires	26 x 12-12
