FrontCuttingDeckLiftCylinders
1
23 4
5 6
7
8
g288167
Figure126
1.Liftcylinder
4.Flangenut
7.Clevispin
2.Pin
5.Cotterpin(2perpin)8.Washer(2perpin)
3.Flangeheadscrew
6.Washer(2perpin)
FrontCuttingDeckLiftCylinderRemoval(Figure126)
1.Parkmachineonalevelsurface,lowercuttingdecksfully,disengagePTO
andstopengine.Removekeyfromthekeyswitch.
2.ReadtheGeneralPrecautionsforRemovingandInstallingHydraulicSystem
Components(page5–73).
3.Topreventcontaminationofhydraulicsystemduringliftcylinderremoval,
thoroughlycleanexteriorofcylinderandttings.
IMPORTANT
Makesuretorelieveliftsystempressurebeforeremovinglift
cylinder.SeeRelievingHydraulicSystemPressure(page5–3).
Groundsmaster
®
5900&5910
Page5–143
HydraulicSystem:ServiceandRepairs
16227SLRevB
