Toshiba B-EX4T2 SERIES - Page 117

7. SUPPLY SPECIFICATIONS ENGLISH VERSION EO1-33094
7.3 Recommended Media and Ribbon Types
E7-15
Print speed Print
Mode
Ribbon Paper
3”/s 5”/s 8”/s 10”/s 12”/s
Print
energy type
Remarks
150LA-1P 0 0 0 0 0 Standard Direct
Thermal
type
NOTES:
*1: Since the print tones provided in the above table are the recommended values, the variance should be
taken into consideration when in use.
*2: The print energy type must be set the above table by all means. For setting method of the print energy
type, refer to the Key Operation Specification.
*3: It limits print tone fine adjustment for the protection of thermal head by the rating of the maximum supply
energy of thermal head. The tone of printing do not thicken even if it is set print tone fine adjustment
value more than the value of the list shown below.
Print tone fine adjustment limit FEAAPrint
energy type
3”/s 5”/s 8”/s 10”/s 12”/s
Standard +10 +10 +10 +10 +6
Wax1 +10 +10 +9 +2 -4
Wax2 +10 +10 +9 +2 -4
Semi-resin1 +10 +10 +10 +8 0
Semi-resin2 +10 +10 +8 +1 -5
Resin1 +10 +10 +10 +4 0
Wax3 +10 +10 +3 -3 -2
Semi-resin3 +10 +10 +3 -2 0
Resin2 +10 +10 0 -2 0
