2. PRINTER SETUP ENGLISH VERSION EO1-33094
2.6 Printer Setting
E2-17
2.6.2 Parameter Setting
(Cont.)
2.6.2.1 Printer Set
(1) MEDIA LOAD
Determines how the use of the [FEED] key enables the printer
to detect the home position. This parameter is effective only
when the sensor type is set to other than “None”.
• OFF Media loading function is disabled (Same as a
feed by [FEED] key)
• STD When the [FEED] key is pressed after the
printer is tuned on, reset in batch mode, or the
print head is closed, the printer detects the
next gap/black mark and feeds the paper from
the sensor to the print start position.
• ECO When the [FEED] key is pressed after the
printer is tuned on, reset in batch mode, or the
print head is closed, the printer detects the
next gap/black mark and feeds the paper to the
print start position based on the last label pitch
printed.
• ECO+Bfeed Since optional ribbon saving module is not
available to the B-EX4T2, MEDIA LOAD
setting and the printer behavior will be
automatically changed to “ECO” setting even if
“ECO+Bfeed” is selected for these models.
(2) FORWARD WAIT
This parameter allows you to choose whether or not to activate
the auto forward wait function. This function, used in the cut
mode, automatically feeds the media forward if there is more
than a 1-second idle time after printing. This prevents the top
edge of the media from curling.
• OFF Disables the auto forward feed wait
• ON Enables the auto forward feed wait → c
c When ON is selected, the feed amount can be fine adjusted.
(3) FORWARD WAIT POS.
(Default: 0.0mm)
.
+5.0mm
-5.0mm
+4.9mm
-4.9mm
NOTE:
1. If the pitch of the media used
for the previous issue was less
than 20mm, the forward wait
will not be activated regardless
of the parameter setting.
2. The media will stay at the
forwarded position even if the
power is turned off/on, the
printer is reset, the print head
is opened/closed.
NOTE:
Underlined setting is the factory
default.
To Next Page
