Toshiba B-EX4T2 SERIES User Manual

2. PRINTER SETUP ENGLISH VERSION EO1-33094
2.6 Printer Setting
E2-22
2.6.2 Parameter Setting
(Cont.)
(16) XML
Select the type of XML data to be printed.
• OFF Disables XML data printing.
• STD Standard specification
• ORACLE Oracle
• SAP SAP
• STD EXT Standard specification (External memory)
• ORACLE EXT Oracle using an external memory
• SAP EXT SAP using an external memory
(17) THRESHOLD SELECT
This parameter is to choose which threshold value for the
media sensor to validate.
• REFLECT Reflective sensor
• TRANS. Transmissive sensor
Then, choose which value to use.
• MANUAL SET Threshold set in the Threshold mode
takes effect.
• COMMAND SET
Threshold set by command takes effect.
(18) ENERGY TYPE
This parameter is intended to make the printer perform
appropriate printing for the supplies to be used. If you use a
different supply from the setting, poor printing may occur.
• TRANSFER Thermal transfer print method → c
• DIRECT Thermal direct print method → d
c When TRANSFER is selected for the Energy type parameter,
choose a ribbon type.
Case of B-EX4T2-GS/TS
• Wax1 Wax 1
• Wax2 Wax 2
• Wax3 Wax 3
• Semi resin1
Semi-resin 1
• Semi resin2 Semi-resin 2
• Semi resin3 Semi-resin 3
• Resin1 Resin 1
• Resin2 Resin 2
• Reserve1 to Reserve2 Reserved
Case of B-EX4T2-HS
• Resin1
Resin 1
• Resin2 Resin 2
• Reserve1 to Reserve8 Reserved
d When DIRECT is selected for the Energy type parameter
• Standard
Standard
• Reserve1 to Reserve9 Reserved

Toshiba B-EX4T2 SERIES Specifications

General

Print Method	Thermal transfer
Resolution	203 dpi
Print Width	104 mm
Interfaces	USB
Optional Interfaces	Wireless LAN
Barcodes	Code 39, Code 128, UPC-A, UPC-E, EAN-8, EAN-13, ITF, Codabar, MSI
2D Codes	Data Matrix, PDF417, QR Code, Maxi Code
Operating Temperature	5°C to 40°C
Storage Temperature	-20°C to 60°C
Humidity	25 - 85% RH (Non-condensing)
