3 Tests and Diagnostics 3.1 The Diagnostic Test
3-2 [CONFIDENTIAL] QOSMIO F20 Maintenance Manual (960-526)
? HARD DISK TEST
? REAL TIMER TEST
? NDP TEST
? EXPANSION TEST
? CD-ROM/DVD-ROM TEST
Other tests are:
? Wireless LAN TEST (Wireless LAN TEST disk)
? LAN/Modem/Bluetooth/IEEE1394 TEST (LAN/Modem/Bluetooth/IEEE1394 TEST disk)
? Sound TEST (Sound TEST disk)
You will need the following equipment to perform some of the Diagnostic test programs.
? The Diagnostic Disks (T&D for maintenance for Main, LAN/Modem/Bluetooth/IEEE1394,
wireless LAN and Sound)
? A formatted working disk (Floppy disk test)
? USB FDD (for all tests)
? A USB test module (USB test )
? A USB cable (USB test)
? An external CRT monitor (Expansion test)
? A CD test media TOSHIBA CD-ROM TEST DISK or ABEX TEST CD-ROM (Sound
test)
? A DVD test media (DVD-ROM TEST DISK TSD-1) (Sound test)
? A music CD (Sound test)
? A store-bought CD-RW media (CD-ROM/DVD-ROM test)
? A microphone (Sound test)
? Headphones (Sound test)
? A cleaning kit to clean the floppy disk drive heads (Head Cleaning)
? An exclusive modem test jig (Nitto Electric Manufacture Co.,Ltd-made QE2000P01)
(Modem test)
? A module cable and RJ11 connector checker (Modem test)
? A LAN wraparound connector (LAN test)
? PC card wraparound connector (Expansion test)
? A display with monitor ID function (Expansion test)
? RS-232C wraparound connector (Async test)
? A PC for wraparound test (Wireless LAN test/Bluetooth test/IEEE1394 test)
