Appendix C Pin Assignments Appendices
QOSMIO F20 Maintenance Manual (960-526) [CONFIDENTIAL] C-11
C.5 IS2110 PC card I/F connector (68-pin)
Table C-5 PC card I/F connector (68-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 GND - 2 ACAD00-EYP I/O
3 ACAD01-EYP I/O 4 ACAD03-EYP I/O
5 ACAD05-EYP I/O 6 ACAD07-EYP I/O
7 ACCBEO-EYN I/O 8 ACAD09-EYP I/O
9 ACAD11-EYP I/O 10 ACAD12-EYP I/O
11 ACAD14-EYP I/O 12 ACCBE1-EYN I/O
13 ACPAR-EYP I/O 14 ACPERR-EYN I/O
15 ACGNT-EYN I/O 16 ACINT-EYN I/O
17 MCVCCA-EYV I/O 18 MCVPPA-EYV I/O
19 ACCLK-EYP I/O 20 ACIRDY-EYN I/O
21 ACCBE2-EYN I/O 22 ACAD18-EYP I/O
23 ACAD20-EYP I/O 24 ACAD21-EYP I/O
25 ACAD22-EYP I/O 26 ACAD23-EYP I/O
27 ACAD24-EYP I/O 28 ACAD25-EYP I/O
29 ACAD26-EYP I/O 30 ACAD27-EYP I/O
31 ACAD29-EYP I/O 32 ACD02-EYP I/O
33 ACCLKR-EYN I/O 34 GND -
35 GND - 36 ACCD1-E3N I/O
37 ACAD02-EYP I/O 38 ACAD04-EYP I/O
39 ACAD06-EYP I/O 40 ACD14-EYP I/O
41 ACAD08-EYP I/O 42 ACAD10-EYP I/O
43 ACVS1-E3P I/O 44 ACAD13-EYP I/O
45 ACAD15-EYP I/O 46 ACAD16-EYP I/O
47 ACA18-EYP I/O 48 ACLOCK-EYN I/O
49 ACSTOP-EYN I/O 50 ACDEVS-EYN I/O
51 MCVCCA-EYV I 52 MCVPPA-EYV I/O
53 ACTRDY-EYN I/O 54 ACFRAM-EYN I/O
55 ACAD17-EYP I/O 56 ACAD19-EYP I/O
57 ACVS2-E3P I/O 58 ACRST-EYN I/O
59 ACSERR-EYN I/O 60 ACREQ-EYN I/O
61 ACCBE3-EYN I/O 62 ACAUDI-EYP O
63 ACSTSC-EYP O 64 ACAD28-EYP I/O
65 ACAD30-EYP I/O 66 ACAD31-EYP I/O
67 ACCD2-E3N O 68 GND -
1T GND - 2T GND -
