Toshiba QOSMIO F20

Appendices Appendix C Pin Assignments
C-22 [CONFIDENTIAL] QOSMIO F20 Maintenance Manual (960-526)
C.19 CN5080 RGB I/F connector (15-pin)
Table C-19 RGB I/F connector (15-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 SYSRED-PXP I 2 SYSGREEN-PXP I
3 SYSBLUE-PXP I 4 N.C -
5 GND - 6 GND -
7 GND - 8 GND -
9 DDC-P5V - 10 GND -
11 N.C - 12 (ALDSDA-P2P) I/O
13 (HSYNC-P3P) O 14 (VSYNC-P3P) O
15 (ALDSCL-P2P) I/O
C.20 CN5501 S-VIDEO I/F connector (4-pin)
Table C-20 S-VIDEO I/F connector (4-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 GND - 2 GND -
3 LUMINA-PYP O 4 CHROMA-PYP O
1T GND - 2T GND -
3T GND - 4T GND -
