3.2 Executing the Diagnostic Test 3 Tests and Diagnostics
QOSMIO F20 Maintenance Manual (960-526) [CONFIDENTIAL] 3-7
Selecting YES of ERROR STOP stops the test program when an error is found and displays the
operation guide on the right side of the display screen as shown below:
ERROR STATUS NAME [[ HALT OPERATION ]]
1: Test end
2: Continue
3: Retry
These three selections have the following functions respectively:
1. Terminates the test program and exits to the subtest menu.
2. Continues the test.
3. Restarts the test from the error.
Selecting NO keeps the test running even if an error is found. When an error occurred, the error
status is displayed and one error is added to the error counter.
Table 3-1 in section 3.5 describes the function of each test on the subtest menu. Table 3-2 in
section 3.18 describes the error codes and error status for each error.
Details of tests in DIAGNOSTIC TEST MENU are described on and after section 3.6. As for
other service programs, refer to section 3.20 to 3.25.
3.2.2 H/W initial information setting tool
After selecting this test, the following menu appears in the display.
##################################################################
###### H/W initial information setting tool VX.XX
#####
##################################################################
#
* 1 ………………………… Initial configuration *
* 3 ………………………… DMI information save *
* 4 ………………………… DMI information recovery
*
* 8 ………………………… System configuration display
*
* 9 ………………………… E2PROM test (MAC/GUID/DMI) *
******************************************************************
*
... Press test number [1,3,4,8,9] ?
For more details on this test, refer to the section 3.3.
