1 Hardware Overview 1.5 Keyboard
1-24 [CONFIDENTIAL] QOSMIO F20 Maintenance Manual (960-526)
1.5 Keyboard
A keyboard which consists of 85(US)/86(UK) keys is mounted on the system unit. The
keyboard is connected to membrane connector on the system board and controlled by the
keyboard controller.
Figure 1-7 is a view of the keyboard.
Figure 1-7 Keyboard
See Appendix E for details of the keyboard layout.
