Appendix C Pin Assignments Appendices
QOSMIO F20 Maintenance Manual (960-526) [CONFIDENTIAL] C-17
C.9 CN3010 MDC I/F connector (12-pin)
Table C-9 MDC I/F connector (12-pin)
PIN
No.
Signal name I/O PIN No. Signal name I/O
1 GND - 2 N.C. -
3 M97OT2-P3P I/O 4 N.C. -
5 GND - 6 E3V -
7 M97SY2-P3P I 8 GND -
9 M97IN2-E3P O 10 GND -
11 M97RS2-S3N I 12 X97BC2-P3P O
1T GND - 2T GND -
3T GND - 4T GND -
5T GND - 6T GND -
