4 Replacement Procedures 4.6 Keyboard
4-18 [CONFIDENTIAL] QOSMIO F20 Maintenance Manual (960-526)
4.6 Keyboard
Removing the keyboard
The following describes the procedure for removing the keyboard (See Figure 4-9 to 4-11).
CAUTION: As the keytop may fall out, when handling the keyboard always hold it by the
frame and do not touch the keytop.
1. Turn the computer face up and open the display.
2. Insert your finger into the spaces between the speaker cover and the computer. Then,
lift up the speaker cover to unlatch and remove it.
Figure 4-9 Removing the speaker cover
Speaker cover
To Next Page
