Appendices Appendix C Pin Assignments
C-32 [CONFIDENTIAL] QOSMIO F20 Maintenance Manual (960-526)
VG Board (FUTVG*)
C.35 CN5901 PCI-EX I/F connector (230-pin)
Table C-35 PCI-EX I/F connector (230-pin)(1/4)
PIN No. Signal name I/O PIN No. Signal name I/O
1 PVT-EFV - 2 1R5-P1V -
3 PVT-EFV - 4 1R5-P1V -
5 PVT-EFV - 6 1R5-P1V -
7 PVT-EFV - 8 1R5-P1V -
9 PVT-EFV - 10 1R5-P1V -
11 PVT-EFV - 12 1R5-P1V -
13 PVT-EFV - 14 (L1INE1-PXP) -
15 PVT-EFV - 16 GND -
17 N.C. - 18 GND -
19 (L1INE2-PXP) - 20 GND -
21 (L1INE3-PXP) - 22 GND -
23 PGN - 24 GND -
25 GND - 26 GND -
27 TXCK1-P3N O 28 TXCK0-P3N O
29 TXCK1-P3P O 30 TXCK1-P3P O
31 GND - 32 GND -
33 TXCK4-P3N O 34 TXDT0-P3P O
35 TXCK4-P3P O 36 TXDT0-P3N O
37 TXCK5-P3N O 38 TXDT1-P3P O
39 TXCK5-P3P O 40 TXDT1-P3N O
41 GND - 42 GND -
43 TXCK6-P3N O 44 TXDT2-P3P O
45 TXCK6-P3P O 46 TXDT2-P3N O
47 (TXDT7-P3N) - 48 (TXDT3-P3P) -
49 (TXDT7-P3P) - 50 (TXDT3-P3N) -
51 GND - 52 GND -
53 GND - 54 GND -
55 PEGC15-P1N O 56 PECG15-P1N I
