Appendix C Pin Assignments Appendices
QOSMIO F20 Maintenance Manual (960-526) [CONFIDENTIAL] C-31
C.33 J9550 TV-in connector (5-pin)
Table C-33 TV-in connector (5-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 R I 2 TV-GND -
3 CVBB - 4 L I
5 TV-GND -
C.34 CN9550 S-Video OUT connector (12-pin)
Table C-34 S-Video OUT connector (12-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 F-GND - 2 F-GND -
3 CVBB - 4 TV-GND -
5 N.C. - 6 TVA-P3V -
7 N.C. 8 TV-GND -
9 R O 10 TV-GND -
11 L O 12 TV-GND -
