Appendix C Pin Assignments Appendices
QOSMIO F20 Maintenance Manual (960-526) [CONFIDENTIAL] C-5
C.2 CN1400 SO-DIMM1 connector (200-pin)
Table C-2 SO-DIMM1 connector (200-pin) (1/4)
PIN No. Signal name I/O PIN No. Signal name I/O
1 MRREF-B0V - 2 GND -
3 GND - 4 ADQ04-B1P I/O
5 ADQ00-B1P I/O 6 ADQ05-B1P I/O
7 ADQ01-B1P I/O 8 GND -
9 GND - 10 ADM0-B1P I/O
11 ADQS0-B1N I/O 12 GND -
13 ADQS0-B1P I/O 14 ADQ02-B1P I/O
15 GND - 16 ADQ07-B1P I/O
17 ADQ03-B1P I/O 18 GND -
19 ADQ06-B1P I/O 20 ADQ12-B1P I/O
21 GND - 22 ADQ13-B1P I/O
23 ADQ08-B1P I/O 24 GND -
25 ADQ09-B1P I/O 26 ADM1-B1P I/O
27 GND - 28 GND -
29 ADQS1-B1N I/O 30 MCK0-B1P O
31 ADQS1-B1P I/O 32 MCK0-B1N O
33 GND - 34 GND -
35 ADQ14-B1P I/O 36 ADQ10-B1P I/O
37 ADQ15-B1P I/O 38 ADQ11-B1P I/O
39 GND - 40 GND -
41 GND - 42 GND -
43 ADQ16-B1P I/O 44 ADQ20-B1P I/O
45 ADQ17-B1P - 46 ADQ21-B1P I/O
47 GND - 48 GND -
49 ADQS2-B1N I/O 50 NC -
51 ADQS2-B1P I/O 52 ADM2-B1P I/O
53 GND - 54 GND -
55 ADQ23-B1P I/O 56 ADQ19-B1P I/O
57 ADQ22-B1P I/O 58 ADQ18-B1P I/O
To Next Page
