Appendices Appendix C Pin Assignments
C-6 [CONFIDENTIAL] QOSMIO F20 Maintenance Manual (960-526)
Table C-2 SO-DIMM1 connector (200-pin) (2/4)
PIN No. Signal name I/O PIN No. Signal name I/O
59 GND - 60 GND -
61 ADQ24-B1P I/O 62 ADQ29-B1P I/O
63 ADQ25-B1P I/O 64 ADQ28-B1P I/O
65 GND - 66 GND -
67 ADM3-B1P I/O 68 ADQS3-B1N I/O
69 NC - 70 ADQS3-B1P I/O
71 GND - 72 GND -
73 ADQ27-B1P I/O 74 ADQ30-B1P I/O
75 BDQ26-B1P I/O 76 ADQ31-B1P I/O
77 GND - 78 GND -
79 MCKE0-B1P O 80 MCKE1-B1P O
81 1R8-B1V - 82 1R8-B1V -
83 NC - 84 NC -
85 ABS2-B1P O 86 NC -
87 1R8-B1V - 88 1R8-B1V -
89 AMA12-B1P O 90 AMA11-B1P O
91 AMA09-B1P O 92 AMA07-B1P O
93 AMA08-B1P O 94 AMA06-B1P O
95 1R8-B1V - 96 1R8-B1V I
97 AMA05-B1P O 98 AMA04-B1P O
99 AMA03-B1P O 100 AMA02-B1P O
101 AMA01-B1P O 102 AMA00-B1P O
103 1R8-B1V - 104 1R8-B1V -
105 AMA10-B1P O 106 ABS1-B1P O
107 ABS0-B1P O 108 ARAS-B1N I
109 AWE-B1N I 110 MCS0-B1N O
111 1R8-B1V - 112 1R8-B1V -
113 ACAS-B1N O 114 MODT0-B1P O
115 MCS1-B1N O 116 AMA13-B1P I/O
117 1R8-B1V - 118 1R8-B1V -
119 MODT1-B1P O 120 NC -
121 GND - 122 GND -
