Appendix C Pin Assignments Appendices
QOSMIO F20 Maintenance Manual (960-526) [CONFIDENTIAL] C-7
Table C-2 SO-DIMM1 connector (200-pin) (3/4)
PIN No. Signal name I/O PIN No. Signal name I/O
123 ADQ32-B1P I/O 124 ADQ36-B1P I/O
125 ADQ33-B1P I/O 126 ADQ37-B1P I/O
127 GND - 128 GND -
129 ADQS4-B1N I/O 130 ADM4-B1P O
131 ADQS4-B1P I/O 132 GND -
133 GND - 134 ADQ38-B1P I/O
135 ADQ34-B1P I/O 136 ADQ35-B1P I/O
137 ADQ39-B1P I/O 138 GND -
139 GND - 140 ADQ40-B1P I/O
141 ADQ45-B1P I/O 142 ADQ44-B1P I/O
143 ADQ41-B1P I/O 144 GND -
145 GND - 146 ADQS5-B1N I/O
147 ADM5-B1P O 148 ADQS5-B1P I/O
149 GND - 150 GND -
151 ADQ42-B1P I/O 152 ADQ46-B1P I/O
153 ADQ43-B1P I/O 154 ADQ47-B1P I/O
155 GND - 156 GND -
157 ADQ48-B1P I/O 158 ADQ52-B1P I/O
159 ADQ49-B1P I/O 160 ADQ53-B1P I/O
161 GND - 162 GND -
163 NC - 164 MCK1-B1P O
165 GND - 166 MCK1-B1N O
167 ADQS6-B1N I/O 168 GND -
169 ADQS6-B1P I/O 170 ADM6-B1P O
171 GND - 172 GND -
173 ADQ55-B1P I/O 174 ADQ54-B1P I/O
175 ADQ51-B1P I/O 176 ADQ50-B1P I/O
177 GND - 178 GND -
179 ADQ56-B1P I/O 180 ADQ60-B1P I/O
181 ADQ57-B1P I/O 182 ADQ61-B1P I/O
183 GND - 184 GND -
185 ADM7-B1P O 186 ADQS7-B1N I/O
