Appendices Appendix C Pin Assignments
C-8 [CONFIDENTIAL] QOSMIO F20 Maintenance Manual (960-526)
Table C-2 SO-DIMM1 connector (200-pin) (4/4)
PIN No. Signal name I/O PIN No. Signal name I/O
187 GND - 188 ADQS7-B1P I/O
189 ADQ58-B1P I/O 190 GND -
191 ADQ59-B1P I/O 192 ADQ62-B1P I/O
193 GND - 194 ADQ63-B1P I/O
195 SMBDAT-P3P I/O 196 GND -
197 SMBCL2-P3P I/O 198 GND -
199 P3V - 200 GND -
1T GND - 2T GND -
