Appendix C Pin Assignments Appendices
QOSMIO F20 Maintenance Manual (960-526) [CONFIDENTIAL] C-29
C.29 CN9650 SW FPC I/F connector (20-pin)
Table C-29 SW FPC I/F connector (20-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 PNLOFF-S3N I 2 GNBTNE-S3N I
3 GNBTND-S3P I 4 GNBTNC-S3N I
5 GNBTNB-S3N I 6 GNBTNA-S3N I
7 GND - 8 GND -
9 KBSC16-S3N O 10 N.C. -
11 KBRT00-S3N O 12 KBRT01-S3N O
13 KBRT02-S3N O 14 KBRT03-S3N O
15 CDBTN-S3N I 16 TVBTN-S3N I
17 PWRSW-S3N I 18 N.C. -
19 GND - 20 (P5V) -
1T GND - 2T GND -
