Appendices Appendix C Pin Assignments
C-18 [CONFIDENTIAL] QOSMIO F20 Maintenance Manual (960-526)
C.10 CN3200 Keyboard connector (34-pin)
Table C-10 Keyboard connector (34-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 NUMLED-P5N I 2 ARWLED-P5N I
3 CAPLED-P5N I 4 P5V I
5 KBSC00-S3N O 6 KBSC01-S3N O
7 KBSC02-S3N O 8 KBSC03-S3N O
9 KBSC04-S3N O 10 KBSC05-S3N O
11 KBSC06-S3N O 12 KBRT00-S3N O
13 KBSC07-S3N O 14 KBSC08-S3N O
15 KBSC09-S3N O 16 KBRT01-S3N O
17 KBRT02-S3N O 18 KBRT03-S3N O
19 KBSC10-S3N O 20 KBSC11-S3N O
21 KBRT04-S3N O 22 KBRT05-S3N O
23 KBSC12-S3N O 24 KBSC13-S3N O
25 KBRT06-S3N O 26 KBRT07-S3N O
27 KBSC14-S3N O 28 KBSC15-S3N O
29 N.C. - 30 N.C. -
31 N.C. - 32 N.C. -
33 N.C. - 34 P5V I
1T GND - 2Y GND -
C.11 CN3240 PAD connector (4-pin)
Table C-11 PAD connector (4-pin))
PIN No. Signal name I/O PIN No. Signal name I/O
1 P5V - 2 IPDDAT-P5P I/O
3 IPDCLK-P5P I/O 4 GND -
1T GND - 2T GND -
