Appendices Appendix C Pin Assignments
C-16 [CONFIDENTIAL] QOSMIO F20 Maintenance Manual (960-526)
Table C-8 WW Tuner I/F connector (124-pin) (2/2)
PIN No. Signal name I/O PIN No. Signal name I/O
61 IRDY-P3N I/O 62 GND -
63 P3V I 64 FRAME-P3N I/O
65 CLKRUN-P3N I/O 66 TDRY-P3N I/O
67 SERR-P3N I/O 68 STOP-P3N I/O
69 GND - 70 T-P3V P3V I
71 PERR-P3N I/O 72 DEVSEL-P3N I/O
73 CBE1-P3N I 74 GND -
75 AD14-P3P I/O 76 AD15-P3P I/O
77 GND - 78 AD13-P3P I/O
79 AD12-P3P I/O 80 AD11-P3P I/O
81 AD10-P3P I/O 82 GND -
83 GND - 84 AD09-P3P I/O
85 AD08-P3P I/O 86 CBE0-P3N O
87 AD07-P3P I/O 88 T-P3V P3V I
89 P3V - 90 AD06-P3P I/O
91 AD05-P3P I/O 92 AD04-P3P I/O
93 N.C. - 94 AD02-P3P I/O
95 AD03-P3P I/O 96 AD00-P3P I/O
97 P5V I 98 P5V -
99 AD01-P3P I/O 100 N.C. -
101 GND - 102 TMPTUN-GND -
103 N.C. - 104 (TMPTUN-SXP) -
105 1R5-P1V - 106 (TMPMPG-SXP)
-
107 1R5-P1V - 108 1R5-P1V -
109 1R5-P1V - 110 N.C. -
111 N.C. - 112 N.C. -
113 GND - 114 GND -
115 N.C. - 116 GND -
117 GND - 118 GND -
119 GND - 120 GND -
121 N.C. - 122 TADCEN -
123 P5V - 124 N.C. -
1T GND - 2T GND -
