4.17 CPU heat sink/CPU 4 Replacement Procedures
QOSMIO F20 Maintenance Manual (960-526) [CONFIDENTIAL] 4-47
2. Unlock the CPU by rotating the cam on the CPU socket 180 degrees to the
counterclockwise with a flat-blade screwdriver.
3. Remove the CPU.
Figure 4-35 Removing the CPU
Cam
