4.19 Touch pad/Volume knob 4 Replacement Procedures
QOSMIO F20 Maintenance Manual (960-526) [CONFIDENTIAL] 4-55
Installing the volume knob
The following describes the procedure for installing the volume knob (See Figure 4-41).
1. Insert the volume knob in the hole.
2. Insert the connector side of volume board cable in the hole and place the volume
board in the slot.
3. Install the volume cover and secure it with the following screws.
? M2.5?3B U-THIN HEAD x2
4. Pass the volume board cable in the slot and stick insulator on it.
