4 Replacement Procedures 4.20 LCD unit/FL inverter
4-62 [CONFIDENTIAL] QOSMIO F20 Maintenance Manual (960-526)
Installing the LCD unit/FL Inverter
The following describes the procedure for installing the LCD unit and FL inverter (See
Figure 4-42 to 4-47).
1. Secure the LCD supports (left and right) to the LCD unit with the following screws.
? M2?3S S-THIN HEAD x4
2. Install the LDC harness and secure the LCD cable holder with the following screw.
? M2.5?6S TAPPING x1
3. Stand the LCD unit on the display cover and connect the LCD harness to the
connector on the back of LCD.
4. Stick the aluminum tape on the connector of LCD harness.
5. Secure the LCD unit with the following screws.
? M2x6S BIND x4
6. Connect LCD harnesses to the connector CN1 and CN2 of the FL inverter.
CAUTION: Be careful not to connect the LCD harnesses to the wrong connectors.
7. Connect HV harnesses to the connector CN3 and CN4 of the FL inverter.
8. Install the FL inverter with the following screw.
? M2?6S BIND x1
9. Stick one insulator on the FL inverter and insert one insulator under the LCD unit.
10. Install the display mask and lock the latches.
NOTE: When installing the display mask, ensure that there is no gap between the display
mask and the display cover.
11. Secure the display mask with the following screws and stick six rubber cushions on
the front.
? M2.5?6B FLAT BIND x6
