4 Replacement Procedures 4.23 Battery lock / Battery latch
4-68 [CONFIDENTIAL] QOSMIO F20 Maintenance Manual (960-526)
Installing the Battery lock / Battery latch
The following describes the procedure for installing the Battery lock / Battery latch (See
Figure 4-51).
1. Set the spring to the Battery lock.
2. Lock the latches to the Battery lock from the bottom and assemble the Battery lock
assembly.
3. Set the spring to the Battery latch.
4. Lock the latches to the Battery latch from the bottom and assemble the Battery latch
assembly.
