Appendices Appendix B Board Layout
B-4 [CONFIDENTIAL] QOSMIO F20 Maintenance Manual (960-526)
Table B-2 System board ICs and connectors (back)
Mark Number Name
(A) CN8800 DC IN connector
(B) CN1410 SO-DIMM0 connector
(C) CN1400 SO-DIMM1 connector
(D) CN3010 MDC I/F connector
(E) CN4611 USB board /F connector
(F) CN1810 ODD connector
(G) CN5900 VG board I/F connector
(H) CN6170 Speaker connector
(I) CN1800 HDD I/F connector
(J) CN6310 Headphone connector
(K) J6051 External microphone connector
(L) CN2400 TV tuner I/F connector
(M) CN4200 IEEE1394 I/F connector
(N) IS2110 PC card connector
(O) CN5501 S-Video OUT connector
(P) CN5080 RGB connector
(Q) PJ8810 Main battery connector
(R) IS1050 CPU socket
(S) IC1200 GMCH
(T) IC8972 PSC
(U) IC3400 Super IO
(V) IC2000 PC card controller
(W) IC1600 ICH6-M
(X) CN4100 LAN I/F connector
