Toshiba RemotEye 4 - Bacnet Binary Input Point Mapping for 4300

174 RemotEye 4 User Manual – 90988-007
C.2 BACNET BINARY INPUT POINT MAPPING FOR 4300
ALL – BACnet Object: Binary Input BACnet Property: Present Value Out of Service: FALSE
Access: Read Only Status Flags: Normal
4300 BACnet Binary Input Point Mapping
Inst. ID
Object Name & Description
Units
Comments
RMTI
-4
Status
1
RemotEye 4 Data Link
True/False (1/0)
0 = Link Up; 1 = Link Down
2
RemotEye 4 Network Link
True/False (1/0)
0 = Link Up; 1 = Link Down
UPS Mode
3
Online Mode
True/False (1/0)
4
Backup Mode
True/False (1/0)
5
Bypass Mode
True/False (1/0)
6
Shutdown Mode
True/False (1/0)
Battery Status
7
UPS Battery Status Unknown
True/False (1/0)
8
UPS Battery Status Normal
True/False (1/0)
9
UPS Battery Status Low
True/False (1/0)
10
UPS Battery Status Depleted
True/False (1/0)
11
UPS Battery Status Discharging
True/False (1/0)
12
UPS Battery Status Test Failure
True/False (1/0)
Batt
. Chrg
Status
13
Protective Charging Set
True/False (1/0)
14
Equalized Charging Set
True/False (1/0)
Batt
.
Test
15
Battery Test Disabled
True/False (1/0)
16
Battery Test in Progress
True/False (1/0)
EMD
17
EMD Enabled
True/False (1/0)
18
EMD Alarm-1
True/False (1/0)
0 = no Alarm; 1 = Alarm Triggered
(upsAlarmEMDSensor1AlarmTriggered)
19
EMD Alarm-2
True/False (1/0)
0 = no Alarm; 1 = Alarm Triggered
(upsAlarmEMDSensor2AlarmTriggered)
