Toshiba Tosvert VF-S15 User Manual

E6582175
F-7
6
 How to use the guidance function
Here are the steps to follow to set parameters, using the guidance function. (When the Preset speed guidance
auf = 2)
Operation panel
action
LED display Operation
00
Displays the operation frequency (output stopped).
(When standard monitor display selection = is set to 0
[output frequency]).

The first basic parameter "History ()" is displayed.

Turn the setting dial to select the guidance function ().

Press the center of the setting dial to display .

Turn the setting dial to change to the setting value "".

Press the center of the setting dial to display the purpose-specific
guidance parameter group (refer to following table).
* * * *
After moving to the purpose-specific guidance parameter group, use
the setting dial to change the parameters.

 is displayed on completion of the setting of the guidance
parameter group.
Display of parameter
↓

↓

↓

Press the MODE key to exit the guidance parameter group.
Thereafter, return to the default monitoring mode (display of output
frequency) by pressing the MODE key.
If there is anything you do not understand during this operation, press the MODE key several times to start over from
he step of  display.
 or  is affixed respectively to the first or last parameter in each guidance wizard parameter group.
MODE
MODE
MODE
MODE

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
