Toshiba Tosvert VF-S15 User Manual

E6582175
J-1
10
10. Peripheral devices
Warning
Mandatory
action
 When using switchgear for the inverter, it must be installed in a cabinet.
Failure to do so can lead to risk of electric shock.
Be Grounded
 Ground must be connected securely.
If the ground is not securely connected, it could lead to electric shock or fire.
10.1 Selection of wiring materials and devices
 Selection of wire size
Voltage
class
Applicable
motor
(kW)
Wire size (mm²) Note 4)
Power circuit Note 1) Note 5)
DC Reactor (Optional)
Input Output
without DCL with DCL
IEC
Compliant
For Japan
*1
IEC
Compliant
For Japan
*1
IEC
Compliant
For Japan
*1
IEC
Compliant
For Japan
*1
3 phase
240V
class
0.4 1.5 2.0 1.5 2.0 1.5 2.0 1.5 2.0
0.75 1.5 2.0 1.5 2.0 1.5 2.0 1.5 2.0
1.5 1.5 2.0 1.5 2.0 1.5 2.0 1.5 2.0
2.2 2.5 2.0 1.5 2.0 1.5 2.0 1.5 2.0
4.0 4.0 2.0 2.5 2.0 2.5 2.0 4.0 2.0
5.5 10 5.5 4.0 2.0 6.0 3.5 6.0 3.5
7.5 16 8.0 6.0 3.5 10 3.5 10 5.5
11 25 14 10 5.5 16 8.0 16 8.0
15 35 22 16 14 25 14 25 14
18.5 50 22 25 14 35 14 35 22
1 phase
240V
class
0.2 1.5 2.0 1.5 2.0 1.5 2.0 1.5 2.0
0.4 1.5 2.0 1.5 2.0 1.5 2.0 1.5 2.0
0.75 1.5 2.0 1.5 2.0 1.5 2.0 1.5 2.0
1.5 2.5 2.0 2.5 2.0 1.5 2.0 2.5 2.0
2.2 4.0 2.0 4.0 2.0 1.5 2.0 4.0 2.0
3.0 4.0 2.0 4.0 2.0 1.5 2.0 4.0 2.0
3 phase
500V
class
0.4 1.5 2.0 1.5 2.0 1.5 2.0 1.5 2.0
0.75 1.5 2.0 1.5 2.0 1.5 2.0 1.5 2.0
1.5 1.5 2.0 1.5 2.0 1.5 2.0 1.5 2.0
2.2 1.5 2.0 1.5 2.0 1.5 2.0 1.5 2.0
4.0 2.5 2.0 1.5 2.0 1.5 2.0 1.5 2.0
5.5 4.0 2.0 1.5 2.0 2.5 2.0 2.5 2.0
7.5 6.0 3.5 2.5 2.0 2.5 2.0 4.0 2.0
11 10 5.5 4.0 2.0 6.0 3.5 6.0 3.5
15 16 8.0 6.0 3.5 10 3.5 10 5.5
18.5 16 8.0 10 5.5 10 5.5 16 8.0

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
