5. Main parameters
Here are described main parameters you set before use according to the section 11. Tables of parameters and data.
5.1 Meter setting and adjustment
 : Meter selection  : Meter adjustment gain
 Function
Output of 0 - 1mAdc, 0 (4) - 20mAdc, 0 - 10vdc can be selected for the output signal from the FM
terminal, depending on the  setting. Adjust the scale at .
Use an ammeter with a full-scale 0 - 1mAdc meter.
The  (analog output bias) needs to be adjusted if output is 4 - 20mAdc.
[Parameter setting]
Title Function Adjustment range
Supposition output at
fsl=17
Default setting

Meter
selection
0: Output frequency
1: Output current
2: Frequency command value
3: Input voltage (DC detection)
4: Output voltage (command value)
5: Input power
6: Output power
7: Torque
8: -
9: Motor cumulative load factor
10: Inverter cumulative load factor
11: PBR (Braking resistor) cumulative
load factor
12: Stator frequency
13: VIA input value
14: VIB input value
15: Fixed output 1
(output current 100% equivalent)
16: Fixed output 2
(output current 50% equivalent)
17: Fixed output 3
(Other than the output current)
18: RS485 communication data
19: For adjustments ( set value is
displayed.)
20: VIC input value
21, 22: -
23: PID feedback value
24: Integral input power
25: Integral output power
26-52:
53: PBR (Braking resistor) load factor
Maximum frequency ()
-
Maximum frequency (fh)
1.5x rated voltage
1.5x rated voltage
1.85x rated power
1.85x rated power
2.5x rated torque
-
Rated load factor
Rated load factor
Rated load factor
Maximum frequency (fh)
Maximum input value
Maximum input value
-
-
-
Maximum value (100.0%)
-
Maximum input value
-
Maximum frequency (fh)
1000x f749
1000x f749
-
Rated load factor
0

Meter
adjustment
gain
- - -
 Resolution: All FM terminals have a maximum of 1/1000.
