E6582175
K-37
11
11.6 Input Terminal Function
It can be assigned the function No. in the following table to parameter f104, f108, f110 to f118, f151 to
f156, a973 to a976.
Table of input terminal functions 1
Function
No.
Code Function Action Reference
0,1 - No function Disabled -
2 F Forward run command ON: Forward run, OFF: Deceleration stop 3.2.1
3 FN Inversion of forward run command Inversion of F 7.2.1
4 R Reverse run command ON: Reverse run, OFF: Deceleration stop
5 RN Inversion of reverse run command Inversion of R
6 ST Standby ON: Ready for operation
OFF: Coast stop (gate OFF)
3.2.1
5.9
7 STN Inversion of standby Inversion of ST 6.7.1
6.34.8
8 RES Reset command 1 ON: Acceptance of reset command, ON → OFF: Trip reset 13.2
9 RESN Inversion of reset command 1 Inversion of RES
10 SS1 Preset-speed command 1
Selection of 15-speed SS1 to SS4 (SS1N to SS4N) (4 bits)
5.7
11 SS1N Inversion of preset-speed command 1 7.2.1
12 SS2 Preset-speed command 2
13 SS2N Inversion of preset-speed command 2
14 SS3 Preset-speed command 3
15 SS3N Inversion of preset-speed command 3
16 SS4 Preset-speed command 4 5.7
17 SS4N Inversion of preset-speed command 4
18 JOG Jog run mode ON: Jogging mode, OFF: Jog run canceled 6.14
19 JOGN Inversion of jog run mode Inversion of JOG
20 EXT Emergency stop by external signal ON: trip stop, OFF: After stopped by f603, e trip 6.29.4
21 EXTN Inversion of emergency stop by external signal Inversion of EXT
22 DB DC braking command ON: DC braking, OFF: Brake canceled 6.12.1
23 DBN Inversion of DC braking command Inversion of DB
24 AD2 2nd acceleration/deceleration ON: Acceleration/deceleration 2
OFF: Acceleration/deceleration 1
6.8.1
6.27.2
25 AD2N Inversion of 2nd acceleration/deceleration Inversion of AD2
26 AD3 3rd acceleration/deceleration ON: Acceleration/deceleration 3
OFF: Acceleration/deceleration 1 or 2
27 AD3N Inversion of 3rd acceleration/deceleration Inversion of AD3
28 VF2 2nd V/F control mode switching ON: 2nd V/F control mode
(V/F fixed, , , , (thr
when f632=2 or 3))
OFF: 1st V/F control mode
( setting, , , , )
6.8.1
29 VF2N Inversion of 2nd V/F control mode switching Inversion of VF2
32 OCS2 2nd stall prevention level ON: Enabled at the value of , and
OFF: Enabled at the value of , and
6.8.1
6.29.2
33 OCS2N Inversion of 2nd stall prevention level Inversion of OCS2
36 PID PID control prohibition ON: PID control prohibited, OFF: PID control enabled 6.24
37 PIDN Inversion of PID control prohibition Inversion of PID
46 OH2 External thermal error input ON: oh2 trip stop, OFF: Disabled 7.2.1
47 OH2N Inversion of external thermal error input Inversion of OH2
48 SCLC Forced local from communication Enabled during communication
ON: Local (Setting of , )
OFF: Communication
6.2.1
6.38
49 SCLCN Inversion of forced local from communication Inversion of SCLC
50 HD Operation hold (hold of 3-wire operation) ON: F (forward run), R: (reverse run) held, 3-wire operation
OFF: Deceleration stop
7.2.1
51 HDN Inversion of operation hold (hold of 3-wire
operation)
Inversion of HD
