8.2 Status monitor mode
8.2.1 Status monitor under normal conditions
In this mode, you can monitor the operation status of the inverter.
To display the operation status during normal operation:
Press the MODE key twice.
Setting procedure (eg. operation at 60Hz)
Item displayed
Panel
operated
LED
display
Communic
ation No.
Description
Output frequency
*
The output frequency is displayed (Operation at
60Hz). (When standard monitor display selection
is set at 0 [output frequency])
Parameter setting
mode
The first basic parameter “” (history function)
is displayed.
Direction of
rotation
FE01
The direction of rotation is displayed.
(: forward run, : reverse run)
Frequency
command value *
FE02
The frequency command value (Hz/free unit) is
displayed.
( In case of = )
Output current *
FC02
The inverter output current (load current) (%/A) is
displayed.
( In case of = )
Input voltage *
FC05
The inverter Input voltage (DC detection) (%/V) is
displayed.
( In case of = )
Output voltage *
FC08
The inverter output voltage (%/V) is displayed.
( In case of = )
Input power *
k12.3
FC06
The inverter input power (kW) is displayed.
( In case of = )
Output power *
h11.8
FC07
The inverter output power (kW) is displayed.
( In case of = )
Inverter
load factor *
FE27
The inverter load factor (%) is displayed.
( In case of = )
Output frequency
*
FE00
The output frequency (Hz/free unit) is displayed.
( In case of = )
* Monitor items can be selected by setting parameters to , (). Refer to Note 12.
Refer to page H-8 and 9 for notes. (Continued overleaf)
Note 1
Note 2
Note 2
Note 3
Note 2
