Toshiba Tosvert VF-S15 User Manual

E6582175
F-119
6
6.31 Override
f205 : VIA input point 1 rate
f206 : VIA input point 2 rate
f214 : VIB input point 1 rate
f215 : VIB input point 2 rate
f220 : VIC input point 1 rate
f221 : VIC input point 2 rate
f660 : Override addition input selection
f661 : Override multiplication input selection
f729 : Operation panel override multiplication gain
• Function
These parameters are used to adjust reference frequencies by means of external input.
[Parameter setting]
Title Function Adjustment range Default setting

VIA input point 1 rate 0-250 (%) 0

VIA input point 2 rate 0-250 (%) 100

VIB input point 1 rate -250-+250 (%) 0

VIB input point 2 rate -250-+250 (%) 100

VIC input point 1 rate 0-250 (%) 0

VIC input point 2 rate 0-250 (%) 100
f660 Override addition input selection
0: Disabled
1: Terminal VIA
2: Terminal VIB
3: Terminal VIC
4:
fc
0
f661
Override multiplication input
selection
0: Disabled
1: Terminal VIA
2: Terminal VIB
3: Terminal VIC
4:
f729
0

Operation panel override
multiplication gain
-100-+100 (%) 0

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
